R5906852-01 F80 series 27
Nb.Name Pcs Description Purpose
8 DP 2 Standard display port For Projector Input
9 DL-DVI-D 2 Dual DVI-I 1.0 (DVI_D
Functionallity).
For Projector Input. These connectors can also
be used to form one uniform image by feeding
half of the image into each connector. HDCP
compliant for sources up 165 Mhz
10 HDMI 1 Standard HDMI 2.0 For Projector Input
11 HDBaseT 1 Standard RJ45 8P8C
Connector
For Projector Control
12 SDI 2 SDI1 is Input, SDI 2 is pass
through. (out)
For Projector Input
Regarding the Trigger Output: If these outputs are loaded too heavy, there is a risk that the projector
will go in reset mode, and restart. This causes no damage to the projector, but is an undesirable
response. This will also happen if the startup current for the external equipment is too high, even
though the nominal power consumption is less than 0,5A.
3.3 Making connections
The source switching time varies from 0.5 to 5 seconds.
Source signal connectivity
The connector panel at the back of the projector is used for all source connections.
Source signal connectivity on the projector is:
• 2x Dual Link DVI-I (DVI-D functionality)
• 2x DisplayPort 1.2
• 1x HDMI 2.0
• 1x HDBaseT
• 1x 3G SDI
3.4 Connector specifications
Overview
•
DVI-I
• Display Port 1.2
• HDMI 2.0
• 3G-SDI
• HDBase T
3.4.1 DVI-I
Specifications
Parameter Value
Connector DVI-I female digital RGB
Signal characteristics DVI 1.0, Digital, TMDS
Input & Communication
