R5906852-01 F80 series60
7.5 HDR – Perceptual Quantizer (PQ)
About PQ
Perceptual Quantizer (PQ) is an electro-optical transfer function (EOTF) that allows for the display of High
Dynamic Range (HDR) content with a luminance level of up to 10 000 cd/m² and can be used with the Rec.
2020 color space.
If your provided HDR content has been mastered with PQ (e.g. Dolby Vision or HDR10), you can adapt the
luminance on screen to adapt to the provided content.
For optimal display of HDR content, this is just one value that will influence the projected image.
When entering the desired screen luminance, take into account the distance of the projector to the
screen and the quality of the screen used.
How to set the PQ?
1. In the main menu, select Image → Advanced → PQ.
Image 7-18
The PQ menu is displayed
Image 7-19
2. Select the desired Unit (nits or foot-lambert).
3. Enter the Screen luminance (either in nits or foot-lambert).
GUI – Image
