R5906852-01 F80 series 29
Parameter Value
Ethernet No
Audio return No
3.4.4 3G-SDI
Specifications
Parameter Value
Standard SMPTE 424M-2006 10bit level A
Connectors 1x) BNC 75 ohm type IEC 60169-8, Amendment 2
1997, A
Bandwidth >3 GHz
Return loss >10dB at 3GHz
Impedance 75 ohm resistive
3.4.5 HDBase T
Specifications
Parameter Value
Reference specification HDBaseT 1.0 Specification, June 2010
Connector Standard RJ-45, 8P8C
Signal characteristics HDBaseT
Max. cable length (1080p/48b/60Hz) 100 m (Cat5e/6), Pixel Clock <=225HHz, Video
Datarate <=5.3Gbps
70 m (Cat5e/6), Pixel Clock >225HHz, Video
Datarate >5.3Gbps
100 m (Cat6a/7), Pixel Clock >225HHz, Video
Datarate >5.3Gbps
Max TMDS Clock Frequency 270 MHz
Max video resolution supported 1920x1200 @60Hz (WUXGA 60Hz)
HDCP Pass-Through Yes, from Source to Projector
IR Extension Not Supported
RS-232 Extension Not Supported
10/100Mbps Ethernet Pass-Through Not Supported
Fallback to 100BaseTx, IEEE 802.3u Not Supported
USB Over Centre Tap Not Supported
Power Over Ethernet Not Supported
Input & Communication
