R5906852-01 F80 series 31
Power Power 5V, max 1,5A (out)
Standard USB 2.0
3.6 LED and Button indication chart
Button Backlight Status
Button Color status Description
Standby button
Blinking WHITE (slow) Projector starts up (booting)
Blinking WHITE (fast) Firmware upgrade
Solid WHITE Projector is in Standby mode
Blinking BLUE Projector goes to ON mode
Solid BLUE Projector is ON
Blinking RED Error condition
Shutter button
Off (no color) Projector is OFF, starts up, or is in
Standby mode.
Solid WHITE Projector is ON, shutter is open
Solid RED Projector is ON, shutter is closed
LED Status
The LED status is located on the top side of the projector, near the IR receiver.
During normal operation the LED is unlit. In the event of a critical error or high temperature, the LED will
display red.
By critical error, the projector cannot be restarted until the projector is disconnected from the power supply
and then reconnected again. If the reason for the error persist, the projector will again go to critical error
status.
By high temperature, the projector will restart when it has cooled down, and temperatures are back within the
normal operating limitations.
