20. DMX chart
Chan-
nel
Function Value
Default
Action
0 - 7 No function
8 - 15 Layout 1 (execution takes 5 sec)
16 - 23 Layout 2 (execution takes 5 sec)
24 - 31 Layout 3 (execution takes 5 sec)
32 - 39 Layout 4 (execution takes 5 sec)
40 - 47 Layout 5 (execution takes 5 sec)
48 - 55 Layout 6 (execution takes 5 sec)
56 - 63 Layout 7 (execution takes 5 sec)
64 - 71 Layout 8 (execution takes 5 sec)
72 - 79 Layout 9 (execution takes 5 sec)
80 - 87 Layout 10 (execution takes 5 sec)
88 - 95 Input select 1
96 - 103 Input select 2
104 - 111 Input select 3
112 - 119 Input select 4
120 - 127
128 - 135
136 - 143
144 - 151
152 - 159
160 - 167
168 - 175
176 - 183
4 Input selection
184 - 255 No function
0 - 31 No function
32 - 63 Focus motor
64 - 95 Zoom motor
96 - 127 Lens shift Right Left
128 - 159 Lens shift Up Down
160 - 191 Power On / Lamp On (together with channel 6 and 7 held in 255
for 5 sec)
192 - 223 Stand By / Lamp Off (together with channel 6 and 7 held in 255
for 5 sec)
5
Function select
224 - 255 Return lens to center position (if held for 5 seconds)
0 - 31 Stop
32 - 63 Run
64 - 223 No function
6 Motor Go >>
224 - 255 Command (see channel 5)
0 - 31 Stop
32 - 63 Run
64 - 223 No function
7
Motor Go <<
224 - 255 Command (see channel 5)
8 Free 0 - 255
