Barco MDSC-8231 User Manual

R5911692 /01 MDSC-823134
5.2.5 Image Flip
About image flip
This function allows you to flip the image on your display.
The available options are:
• Disabled (no image flip applied)
• Mirror (flips the image horizontally, making the left content appear on the right and vice versa)
• Rotation (rotates the image 180°)
When image rotation is selected, the latency will increase with 20 msec. Image mirroring does not
cause any latency increase.
To enable/disable horizontal flip
1. Bring up the OSD main menu.
2. Navigate to the Picture Advanced menu.
3. Enter the Image Flip submenu.
4. Select one of the available options and confirm.
5.2.6 Screen Resolution
About screen resolution
This function allows you to adjust the image resolution of the preferred timing detailed in the EDID exposed to
the DP input.
The available options are:
• 4K (17:9) (for image resolution of 4096 x 2160)
• UHD (16:9) (for image resolution of 3840 x 2160)
Image resolution of the preferred timing detailed in the EDID exposed to HDMI-1 and HDMI-2 are
predefined as follows: HDMI-1 = 16:9; HDMI-2 = 17:9.
To enable/disable horizontal flip
1. Bring up the OSD main menu.
2. Navigate to the Picture Advanced menu.
3. Enter the Screen Resolution submenu.
4. Select one of the available options and confirm.
5.3 Input select menu
5.3.1 Main Source
About main sources
The available main sources for your display are:
• DVI
• SDI 4K
• SDI
• DisplayPort
• HDMI–1
• HDMI–2
The main source can also be quickly selected through the Input selection key ( ), without the need
to navigate through the OSD menu.
Advanced operation

Barco MDSC-8231 Specifications

General

Panel type	IPS-Pro
Color gamut	96 %
Pixel pitch	0.1704 x 0.1704 mm
Screen shape	Flat
Response time	20 ms
Display diagonal	31.1 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Native aspect ratio	17:9
Maximum refresh rate	- Hz
Viewable size, vertical	368 mm
Contrast ratio (typical)	1400:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	698 mm
Display brightness (typical)	550 cd/m²
Supported graphics resolutions	4096 x 2160
DVI-D ports quantity	1
USB upstream port type	USB Type-B
Panel mounting interface	100 x 100, 200 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Power consumption (off)	1 W
Power consumption (standby)	- W
Power consumption (typical)	18 W
Package weight	17000 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	ANSI/AAMI ES60601-1 (2005 + C1:09 + A2:10 + A1:2014 CAN/CSA-C22.2 No. 60601-1 (2014) IEC 60601-1:2005 + CORR. 1:2006 + CORR. 2:2007 + A1:2012 EN 60601-1: 2006 + CORR:2010 + A1:2013 + A12:2014 EMC: IEC 60601-1-2 (2014), EN 60601-1-2 (2015) EN55011 /CISPR 11, FCC CFR47 15 B (B) GB17625.1-2012; GB4943.1-2011; GB/T9254-2008 CE, c-UL-us, DEMKO, CCC, INMETRO, EAC IP20/IP45 ROHS-3, REACH, WEEE
Product color	White
Market positioning	Medical
Sustainability certificates	RoHS

Weight and Dimensions

Depth (without stand)	93 mm
Width (without stand)	777 mm
Height (without stand)	472 mm
Weight (without stand)	12100 g
