Barco MDSC-8231 User Manual

R5911692 /01 MDSC-823136
3. Enter the SDI config submenu.
4. Select one of the available SDI config modes and confirm.
SDI loopthrough (not available in Quad link)
SDI 2: loopthrough of SDI 1
SDI 4: loopthrough of SDI 3
5.3.5 Auto search
About auto search
By enabling the input selection auto search function, the display will automatically detect the connected
source and display it on the screen.
To enable/disable auto search
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the Auto search submenu.
4. Enable/Disable auto search as desired and confirm.
5.3.6 Failover input
About failover input
This function allows the display to automatically switch to a failover (backup) source in case the main source
(DisplayPort, HDMI, SDI 4K) is missing. The display will automatically restore the main source once the signal
is back.
The available failover inputs for your display depend on the selected SDI configuration mode. See the
following table for more details.
Main source Backup source
DP / HDMI / SDI 1
• None
• DVI
• SDI 3 (*1)
DP / HDMI / SDI 1 / SDI 3 (*2)
• None
• DVI
DP / HDMI / QUAD LINK 3G-SDI (*3)
• None
• DVI
The failover input can only be selected when both
1. the Auto search function is disabled (see “Auto search”, page 36), and
2. the PiP/PaP Modes function is disabled (see “Picture and Picture input”, page 37 and “Picture in
Picture input”, page 38).
If any of both functions are enabled then failover will be disabled and made unavailable. As soon as
both functions are disabled again, failover will be enabled and made available again with the
selected failover input.
The failover input will be activated within about 7 seconds after the main source has been lost.
During the transition from main to failover input and vice versa, a text message is visible to inform
the user.
The main source can be changed while the failover input remains unchanged. During the selection
and synchronization of a new main source the failover function is temporary (7 sec) disabled.
Advanced operation

Barco MDSC-8231 Specifications

General

Panel type	IPS-Pro
Color gamut	96 %
Pixel pitch	0.1704 x 0.1704 mm
Screen shape	Flat
Response time	20 ms
Display diagonal	31.1 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Native aspect ratio	17:9
Maximum refresh rate	- Hz
Viewable size, vertical	368 mm
Contrast ratio (typical)	1400:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	698 mm
Display brightness (typical)	550 cd/m²
Supported graphics resolutions	4096 x 2160
DVI-D ports quantity	1
USB upstream port type	USB Type-B
Panel mounting interface	100 x 100, 200 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Power consumption (off)	1 W
Power consumption (standby)	- W
Power consumption (typical)	18 W
Package weight	17000 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	ANSI/AAMI ES60601-1 (2005 + C1:09 + A2:10 + A1:2014 CAN/CSA-C22.2 No. 60601-1 (2014) IEC 60601-1:2005 + CORR. 1:2006 + CORR. 2:2007 + A1:2012 EN 60601-1: 2006 + CORR:2010 + A1:2013 + A12:2014 EMC: IEC 60601-1-2 (2014), EN 60601-1-2 (2015) EN55011 /CISPR 11, FCC CFR47 15 B (B) GB17625.1-2012; GB4943.1-2011; GB/T9254-2008 CE, c-UL-us, DEMKO, CCC, INMETRO, EAC IP20/IP45 ROHS-3, REACH, WEEE
Product color	White
Market positioning	Medical
Sustainability certificates	RoHS

Weight and Dimensions

Depth (without stand)	93 mm
Width (without stand)	777 mm
Height (without stand)	472 mm
Weight (without stand)	12100 g
