R5911692 /01 MDSC-8231 37
(*1) SDI 3 is only available if the SDI configuration is Dual SDI.
(*2) The SDI configuration is Single SDI-1 / Single SDI-3.
(*3) The SDI configuration is Quad-SDI.
To select the failover input
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the Failover Input submenu.
4. Select one of the available failover inputs and confirm.
5.3.7 Picture and Picture input
About Picture and Picture input
This function allows the display to show a second input source on the left side of the display. The Primary input
(main source) is still displayed on the right half of the screen.
The possible Picture and Picture combinations between the Primary input (main source) and the Secondary
input (PaP image) is displayed in the following table.
Primary input Secondary input
DP 1.1
• HDMI 2.0–1
• HDMI 2.0–2
• DVI
• SDI 3 (*)
HDMI 2.0–1
HDMI 2.0–2
• DP 1.1
• DVI
• SDI 3 (*)
DVI
SDI 3 (*)
• DP 1.1
• HDMI 2.0–1
• HDMI 2.0–2
Both primary and secondary input are limited to FHD resolution max.
The Video Parameters applied to the Primary input Source are also applied to the Secondary input.
The 2nd source keeps the same image size (Native/Aspect) as the Primary input Source.
(*) SDI 3 is only available if the SDI configuration mode is Dual SDI.
To select Picture and Picture input
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the PaP Input submenu.
4. Select one of the available PaP sources (or NONE) and confirm.
Advanced operation

Barco MDSC-8231 Specifications

General

Panel type	IPS-Pro
Color gamut	96 %
Pixel pitch	0.1704 x 0.1704 mm
Screen shape	Flat
Response time	20 ms
Display diagonal	31.1 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Native aspect ratio	17:9
Maximum refresh rate	- Hz
Viewable size, vertical	368 mm
Contrast ratio (typical)	1400:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	698 mm
Display brightness (typical)	550 cd/m²
Supported graphics resolutions	4096 x 2160
DVI-D ports quantity	1
USB upstream port type	USB Type-B
Panel mounting interface	100 x 100, 200 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Power consumption (off)	1 W
Power consumption (standby)	- W
Power consumption (typical)	18 W
Package weight	17000 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	ANSI/AAMI ES60601-1 (2005 + C1:09 + A2:10 + A1:2014 CAN/CSA-C22.2 No. 60601-1 (2014) IEC 60601-1:2005 + CORR. 1:2006 + CORR. 2:2007 + A1:2012 EN 60601-1: 2006 + CORR:2010 + A1:2013 + A12:2014 EMC: IEC 60601-1-2 (2014), EN 60601-1-2 (2015) EN55011 /CISPR 11, FCC CFR47 15 B (B) GB17625.1-2012; GB4943.1-2011; GB/T9254-2008 CE, c-UL-us, DEMKO, CCC, INMETRO, EAC IP20/IP45 ROHS-3, REACH, WEEE
Product color	White
Market positioning	Medical
Sustainability certificates	RoHS

Weight and Dimensions

Depth (without stand)	93 mm
Width (without stand)	777 mm
Height (without stand)	472 mm
Weight (without stand)	12100 g
