Barco MDSC-8231 User Manual

R5911692 /01 MDSC-823138
5.3.8 Picture in Picture input
About Picture in Picture input
This function allows the display to show a second input source as an inset window inside the main source.
The possible Picture in Picture combinations between the Primary input (main source) and the Secondary
input (PiP image) is displayed in the following table.
Primary input Secondary input
DP 1.2 MST / 1.1 / Dual
HDMI 2.0–1
HDMI 2.0–2
12G-SDI (on SDI 1)
DVI
SDI 3 (*)
Gamma and Color temperature for the PiP Source are always set to Native and 6500 K
independently from the Transfer Function applied to the Primary input Source.
(*) SDI 3 is only available if the SDI configuration mode is Dual SDI.
To select Picture in Picture input
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the PiP Input submenu.
4. Select one of the available PiP inputs (or NONE) and confirm.
5.3.9 Picture in Picture mode
About Picture in Picture mode
The available Picture in Picture modes for your display are:
• Large PiP: 35% of display horizontal size in top or bottom of right corners
• Small PiP: 25% of display horizontal size in top or bottom of right corners
To select Picture in Picture mode
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the Picture in Picture Mode submenu.
4. Select one of the available Picture in Picture modes and confirm.
5.3.10 Picture in Picture position
About Picture in Picture position
The available Picture in Picture positions for your display are:
• Bottom right
• Top right
To select Picture in Picture position
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the PiP Position submenu.
4. Select one of the available PiP positions and confirm.
Advanced operation

Barco MDSC-8231 Specifications

General

Panel type	IPS-Pro
Color gamut	96 %
Pixel pitch	0.1704 x 0.1704 mm
Screen shape	Flat
Response time	20 ms
Display diagonal	31.1 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Native aspect ratio	17:9
Maximum refresh rate	- Hz
Viewable size, vertical	368 mm
Contrast ratio (typical)	1400:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	698 mm
Display brightness (typical)	550 cd/m²
Supported graphics resolutions	4096 x 2160
DVI-D ports quantity	1
USB upstream port type	USB Type-B
Panel mounting interface	100 x 100, 200 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Power consumption (off)	1 W
Power consumption (standby)	- W
Power consumption (typical)	18 W
Package weight	17000 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	ANSI/AAMI ES60601-1 (2005 + C1:09 + A2:10 + A1:2014 CAN/CSA-C22.2 No. 60601-1 (2014) IEC 60601-1:2005 + CORR. 1:2006 + CORR. 2:2007 + A1:2012 EN 60601-1: 2006 + CORR:2010 + A1:2013 + A12:2014 EMC: IEC 60601-1-2 (2014), EN 60601-1-2 (2015) EN55011 /CISPR 11, FCC CFR47 15 B (B) GB17625.1-2012; GB4943.1-2011; GB/T9254-2008 CE, c-UL-us, DEMKO, CCC, INMETRO, EAC IP20/IP45 ROHS-3, REACH, WEEE
Product color	White
Market positioning	Medical
Sustainability certificates	RoHS

Weight and Dimensions

Depth (without stand)	93 mm
Width (without stand)	777 mm
Height (without stand)	472 mm
Weight (without stand)	12100 g
