Barco MDSC-8231 User Manual

R5911692 /01 MDSC-8231 35
To select the main source
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the Main Source submenu.
4. Select one of the available main sources and confirm.
5.3.2 DisplayPort mode
About DisplayPort mode
The available DisplayPort (DP) modes for your display are:
• DP 1.2 MST L:R (MST stream 1 on Left side/ MST stream 2 on Right side)
• DP 1.2 MST R:L (MST stream 1 on Right side/ MST stream 2 on Left side)
• DP 1.1 main
• DP 1.1 dual
Please refer to the technical specifications for an overview of accepted video formats.
To select the DisplayPort mode
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the DP mode submenu.
4. Select one of the available DisplayPort modes and confirm.
5.3.3 4K SDI mode
About 4K SDI mode
The available 4K SDI modes for your display are:
• Square-division (SQD)
• 2-sample interleave (2SI)
• Auto (*)
(*) Select Auto only when the SDI mode is present in the SDI video stream.
To select the 4K SDI mode
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the 4K SDI mode submenu.
4. Select one of the available 4K SDI modes and confirm.
5.3.4 SDI config
About SDI config
The available SDI config modes for your display are:
• Quad-SDI (Quad link 3G-SDI)
• Dual SDI (Dual input: SDI 1 up to 12G-SDI, SDI 3 up to 3G-SDI)
• Single SDI-1 (up to 12G-SDI)
• Single SDI-3 (up to 12G-SDI)
To select the SDI config mode
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
Advanced operation

Barco MDSC-8231 Specifications

General

Panel type	IPS-Pro
Color gamut	96 %
Pixel pitch	0.1704 x 0.1704 mm
Screen shape	Flat
Response time	20 ms
Display diagonal	31.1 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Native aspect ratio	17:9
Maximum refresh rate	- Hz
Viewable size, vertical	368 mm
Contrast ratio (typical)	1400:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	698 mm
Display brightness (typical)	550 cd/m²
Supported graphics resolutions	4096 x 2160
DVI-D ports quantity	1
USB upstream port type	USB Type-B
Panel mounting interface	100 x 100, 200 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Power consumption (off)	1 W
Power consumption (standby)	- W
Power consumption (typical)	18 W
Package weight	17000 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	ANSI/AAMI ES60601-1 (2005 + C1:09 + A2:10 + A1:2014 CAN/CSA-C22.2 No. 60601-1 (2014) IEC 60601-1:2005 + CORR. 1:2006 + CORR. 2:2007 + A1:2012 EN 60601-1: 2006 + CORR:2010 + A1:2013 + A12:2014 EMC: IEC 60601-1-2 (2014), EN 60601-1-2 (2015) EN55011 /CISPR 11, FCC CFR47 15 B (B) GB17625.1-2012; GB4943.1-2011; GB/T9254-2008 CE, c-UL-us, DEMKO, CCC, INMETRO, EAC IP20/IP45 ROHS-3, REACH, WEEE
Product color	White
Market positioning	Medical
Sustainability certificates	RoHS

Weight and Dimensions

Depth (without stand)	93 mm
Width (without stand)	777 mm
Height (without stand)	472 mm
Weight (without stand)	12100 g
