2. Installation Guidelines
2.3 Battery Insertion in the Remote Control
Where to find the batteries
The batteries are not placed in the remote control to avoid remote control operation in its package, resulting in a shorter battery life
time.
How to install the batteries
1. Push the cover tab (A) with the fingernail a little backwards and pull upwards the cover top (B). (image 2-3)
2. Slide the cover forwards to remove. (image 2-4)
3. Push the battery body towards the spring and lift it up to remove. (image 2-5)
4. Insert two AA size batteries, making sure the polarities match the + and – marks inside the battery compartment (image 2-5).
5. Insert the lower tab of the battery cover in the gap at the bottom of the remote control, and press the cover until it clicks in place
(image 2-4).
Image 2-3
Battery cover unlock
Image 2-4
Battery cover removal
Image 2-5
Battery removal
8 R5976672 SOLARIS LC40 01122003
