7. Image Settings
How to set up
1. Select Total pixels. (menu 7-15)
2. Press ENTER to activate.
A slider bar will be displayed. The actual total pixel setting will inidcated.
3. Use the ↑ or ↓ to set up the total pixels.
Viewport
Horizontal start
Width
Vertical start
Height
Total pixels
Automatic
Back
Menu 7-15
7.9 Phase
About Phase adjustment
When displaying computer patterns or graphics (RGB or YUV signals) which are very detailed (tilting, vertical stripes, etc. ), jitter
in picture (mis-sampling) may occur, causing horizontal stripes in portions of the screen. When this jitter occurs, adjust ’Phase’ for
optimum image.
Image 7-5
Jittering on image
How to change the Phase ?
1. Select Image Settings.
2. Press ENTER to select.
Image settings menu will be displayed (menu 7-16)
3. Select Phase.
44
R5976672 SOLARIS LC40 01122003
