10. Advanced Settings
6. Press ENTER.
The IR address box opens. (menu 10-37)
7. Use ↑ or ↓ to change the value.
Or,
enter the desired value with the digit keys on the RCU.
Or,
turn the thumb wheel until the desired value is displayed and press the thumb wheel.
Advanced Settings
Gamma
Color Temperature
Input Balance
Noise Reduction
Display Settings
Installation
Service
Back
Menu 10-35
Service
Identification
IR address : 004
Serial communication
IR locking
Restore factory defaults
Back
Menu 10-36
IR address
Enter new value
3
Menu 10-37
10.8.3 Serial communication
Overview
• RS232 address
• Changing the baudrate for RS232 communication
10.8.3.1 RS232 address
How to change the RS232 address ?
1. Press ENTER to activate the menu structure.
2. Select Advanced Settings and press ENTER to activate.
The advanced settings menu will be displayed. (menu 10-38)
3. Select Service.
4. Press ENTER to select.
The service menu will be displayed. (menu 10-39)
5. Select Serial communication.
6. Press ENTER.
The serial communication menu opens. (menu 10-40)
7. Select RS232 addre ss and press ENTER.
The RS232 address change menu opens. (menu 10-41)
The first digit will be highlighted.
8. To change the address :
Use ↑ or ↓ to change the value.
For a highlighted value, use ↑ or ↓ to change this value or enter the desired value with the digit keys on the RCU
To go to the next digit : use the ← or → to highlight another value.
Advanced Settings
Gamma
Color Temperature
Input Balance
Noise Reduction
Display Settings
Installation
Service
Back
Menu 10-38
Service
Identification
IR address : 004
Serial communi
cation
IR locking
Restore factory defaults
Back
Menu 10-39
Serial Communication
RS232 address : 001
Baudrate : [57600]
Back
Menu 10-40
RS232 address
Enter new value :
[001]
Back
Menu 10-41
