5. ICMP
119 10
Image 5-9
ICMP (with DisplayPort and HDMI 1.4).
Functionality
8
HDMI A (B)
HDMI 2.0 con nector to connect a video source.
NOTE: It is recomm ended to use the HDM I 2.0 ports for faster transfer of video and audio data.
9
3G-SDI A (B)
SDI connector t o connect a video source.
10
HDMI
HDMI 1.4 con nector to connect a video source.
11
DisplayPort A (B)
DisplayPort connector to con nect a video source.
5.5 ICMP DisplayPort specifications
DisplayPort
Digital display interface developed by the Video Electronics S tandards Association (VESA). This royalty-free interface
is primarily used to connect a video so urce to a display device such as a computer mon itor, though it can also be us ed
to transmit audio, USB, and other forms of data. VESA designed it to replace VGA, DVI, and FPD-Link. B ackwa rd
compatibility to VGA and DVI by using active adapter dongles e nables users to use DisplayPort fitted video sources
without replacing ex isting display devices.
HDCP
High-bandwidth Digital Content Protection is a form of digital copy protection dev eloped by Intel Corporation to p revent
copying of digital audio and v ideo content as it travels across DisplayPort, Digital Visual Interface (DV I), High-Definition
Multimedia Interface ( HDMI), Gigabit Video Interface (GVIF), or Unified Display Interface (UDI) connections, even if
such copy ing would be permitted by fair use laws. The specification is proprietary, and implementing HDCP requires
a license.
