Barco Thor series User Manual

5. ICMP
Port A should contain the 8 most significant bits o f the pixel data, where port B sh ould contain the 8 least
significant bits of the pixel data. The pixel data will be reconstructed using the all 8 bits of port A and using
the 4 most significantbitsofportB.
HDMI 2.0 Supported Passive 3D Formats (3D formats only)
Format Frame Rate Color coding Bit depth
1920x1080
2048x1080
24
30
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
10
12
1920x1080
2048x1080
60
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
3840x2160
4096x2160
24
30
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
In P assive 3D HDMI2 input port A should contain the pixel data of Left Eye and HDMI2 input port B should
contain the pixel data for Right Eye.
5.8 ICMP HDMI 1.4 specifications
HDMI
HDMI (High-Definition Multimedia Interface) is a co mpac t audio/video interface for transferring uncompressed v ideo
data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a com -
patible computer monitor, v ideo pr ojector, digital television, or digital audio device. HDMI is a digital replacement for
existing analog video standards.
HDMI 1.4 specifications
HDMI1.4a, including HD CP1.4
HDMI 1.4 Supported 2D Formats (progressive)
Format Frame Rate
Color coding
Bit depth
720x480 60
RGB
YCbCr 4:4:4
YCbCr 4:2:2
(8)
10
12
720x576 50
RGB
YCbCr 4:4:4
YCbCr 4:2:2
(8)
10
12
1280x720 23.976
24
25
29.97
30
50
59.94
60
100
119.88
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
10
12
44 R5906787 THOR 26/01/2018
