5. ICMP
SMPTE Standard Source Resolution
Frame Rate Display Rate
Scan Type
SMPTE 274M
1920 x 1080 50
59.940
60
50
59.940
60
Interlaced
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XY Z) 4:4:4 10 or 12-Bit
SMPTE 428-9
2048 x 1080 23.976
24
23.976
24
Progressive
Y Cb Cr 4:4:4 12-Bit
RGB (XYZ) 4:4:4 12-Bit
Dual Stream 3G HD -SDI (SMPT E 425) form ats
SMPTE Standard Source Reso lution Frame Rate Display Rat e Scan Type
SMPTE 292M
SMPTE 428-9
1920 x 1080
2048 x 1080
23.976
24
25
29.970
30
47.952
48
50
59.940
60
Progressive
Y Cb Cr 4:2:2 10-Bit
5.7 ICMP HDMI 2.0 specifications
HDMI
HDMI (High-Definition Multimedia Interface) is a co mpac t audio/video interface for transferring uncompressed v ideo
data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a com -
patible computer monitor, v ideo projector, digital television, or digital audio de
vice. HDMI is a digital replacement for
existing analog video standards.
HDMI 2.0 specifications
HDMI
Both HDMI 2.0 inputs are fully com pliant with the HDM I 1.4, 1.4a, 1.4b, 2.0 and 2.0a revisions of the HDMI specification.
Full Ran ge and Lim ited Range Q uantization are supported for all specified formats.
BT.709 and DCI-P3 are supported for all forma ts. For HDR content (UHD and 4K only) the B T.2020 color coding is supported.
All video streams should have a progressive scan orde r, with the excep
tion of 19 20x1080i 60 fps (interlaced scan).
HDCP
Both HDMI 2.0 inputs are HDCP 1.4 & HDCP 2.2 comp liant.
HDR (SMPTE ST 2084)
HDR (High Dynam ic Range) is supported on all UHD and 4K formats.
This inc ludes SMPT E ST 2084 (static metadata) and B T.2020 color coding. Requires a license!
HDMI 2.0 Cable requirements
All HDMI cables should work with HDMI 2 .0 receivers. There is no such thing as a “4K HDM I cable” even though th is is sometimes
sold this way. But of course there are quality differences. The “high-speed” cables w ould be preferred over the “standard-speed”
cables. They usually work at higher cable lengths than the standard -speed ones.
R5906787 THOR 26/01/2018
41
