Installing a GigE Camera
AW00061111000
16
Installation and Setup Guide fo
r ace CL, aviator, beat, pilot
, ra
cer, runner, and sc
out Cameras (Windows)
4.4.2
Connectors of GigE Cameras
Power and I/O
I/O
Only
Power
scout and pilot GigE
runner GigE
Drawings are not to s
cale
aviator GigE
Power and I/O
I/O
Only
Power
racer GigE
Ethernet
Ethernet
Ethernet
Ethernet
21
23
