Basler GigE VISION CAMERAS User Manual

AW00118303000 Acquisition Control
Basler racer GigE 135
Factor 2:
Factor 2 is the exposure time. You can use the formula below to calculate the maximum line rate
based on the exposure time for each acquired line:
Where the constant C
1
depends on the camera model and on whether the parameter limit is
removed from the Exposure Overhead parameter, as shown in the table below:
For more information about setting the exposure time, see Section 8.2.5.2 on page 93. For more
information about removing parameter limits and the implications, see Section 10.2 on page 168.
Factor 3:
Factor 3 is the frame transmission time. You can use the formula below to calculate the maximum
line rate based on the frame transmission time:
Max Lines/s (nominal; based on
sensor readout)
raL2048-
48gm
raL4096-
24gm
raL6144-
16 gm
raL8192-
12 gm
raL12288-
8 gm
80000 80000 80000 80000 80000
raL2048-
48gm
raL4096-
24gm
raL6144-
16 gm
raL8192-
12 gm
raL12288-
8 gm
C
1
(Default Value)
5.4 µs 5.4 µs 5.4 µs 5.4 µs 5.4 µs
C
1
(Limit Removed From
ExposureOverhead
Parameter)
3.4 µs 3.4 µs 3.4 µs 3.4 µs 3.4 µs
Max Lines/s
1
Exposure time in µs C
1
+
--------------------------------------------------------------------=
Max Lines/s
Device Current Throughput Parameter Value
Payload Size Parameter Value
------------------------------------------------------------------------------------------------------------------------


Frame Height=
