Specifications, Requirements, and Precautions AW00118303000
10 Basler racer GigE
1.4.3 Lens Adapter Dimensions
Fig. 4: C-mount Adapter on a racer GigE Camera; Dimensions in mm
17.526
Photosensitive
Surface of the
Sensor
3
Not to Scale
50.83
62
56
42.42
36.12
ø53
ø51.2
5.5
8.41
ø30 ± 0.05
