Basler GigE VISION CAMERAS User Manual

Specifications, Requirements, and Precautions AW00118303000
2 Basler racer GigE
1.2 General Specifications
Specification raL2048-48gm raL4096-24gm
Sensor Size
(Maximum Resolution)
2048 pixels 4096 pixels
Sensor Type Awaiba DR-2k-7
Monochrome Linear CMOS
Awaiba DR-4k-7
Monochrome Linear CMOS
Pixel Size 7 µm x 7 µm
Max Line Rate 51 kHz 26 kHz
Min Line Rate No minimum when an external line trigger signal is used
100 Hz when an external line trigger signal is not used
Mono/Color Mono
Data Output Type Fast Ethernet (100 Mbit/s) or Gigabit Ethernet (1000 Mbit/s)
Pixel Data
Formats
Mono 8
Mono 12
Mono 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV) Packed
ADC Bit Depth 12 bit
Synchronization Via external trigger signal, via software or free run
Exposure Control Programmable via the camera API
Camera Power
Requirements
+12 VDC (- 10 %) to +24 VDC (+ 5 %), < 1 % ripple, supplied via the camera’s 6-pin
connector
Max Power Consumption
(at 12 VDC)
3W 4W
I/O Lines 3 input lines and 2 output lines
Lens Adapter Universal camera front, suitable for C-mount (2k cameras), F-mount, and M42 (×1.0
or ×0.75) adapter. Lens adapter is not in the camera’s scope of delivery and must be
ordered separately as an accessory. See Section 1.4.4 on page 12 for information
about selecting a suitable lens adapter for your camera.
Size
(L x W x H)
36.2 mm x 56 mm x 62 mm (without lens adapter or connectors)
51.0 mm x 56 mm x 62 mm (with C-mount lens adapter and connectors)
79.9 mm x 56 mm x 62 mm (with F-mount lens adapter and connectors)
49.5 mm x 56 mm x 62 mm (with M42-mount lens adapter and connectors)
Table 1: General Specifications - 2k and 4k Mono Cameras
