Physical Interface AW00118303000
52 Basler racer GigE
7.2.2 Pin Assignments for the 12-pin Connector
The 12-pin connector is used to access the three physical input lines and two physical output lines
on the camera. The pin assignments for the connector are shown in Table 6.
7.2.3 Pin Assignments for the RJ-45 Jack
The 8-pin RJ-45 jack provides Ethernet access to the camera. Pin assignments adhere to the
Ethernet standard.
Pin Designation
1 I/O Input 1 -
2 I/O Input 1+
3 I/O Input 3 -
4 I/O Input 3 +
5Gnd
6 I/O Output 1-
7 I/O Output 1 +
8 I/O Input 2 -
9 I/O Input 2 +
10 Not connected
11 I/O Output 2 -
12 I/O Output 2+
Table 6: Pin Assignments for the 12-pin Connector
NOTICE
 Using a wrong pin assignment for the 12-pin connector can severely damage the camera.
Make sure the cable and plug you connect to the 12-pin connector follows the correct pin
assignment. In particular, do not use a pin assignment that would be correct for Basler area
scan cameras. The 12-pin connectors of Basler line scan and area scan cameras are
electrically incompatible.
For the I/O lines to work correctly, pin 5 must be connected to ground.
