Maintenance DTA 100 C
74 / 90 822-129-8
Cleaning the device surfaces and connection cable
1. Clean the device surfaces and connection cable with mild detergent and a lint-free cloth.
2. NOTICE! Damage to device due to leaking fluids. Do not allow liquids to leak into
devices.
16.2 Replacing the printer paper roll
Prerequisites
Paper scissors for cutting the paper roll.
Paper roll for printer, plain paper, Ø 30 cm, width 57 mm
Order number: 565-514
Procedure
1 Cover
2 Latches
3 Paper roll
4 Paper roll holder
5 Groove
1. Remove the cover (1) from the printer.
2. Press both latches (2) inwards and remove the printer.
3. Remove the paper roll holder (4).
4. Remove the empty paper roll.
