baxter AK 98 Quick Reference Guide

17. Information tab
18. Treatment graph tab
19. Information field
20. Patient page
21. Functions button
22. Disinfection button
23. Blood button
24. Fluid button
25. Fluid bypass button
26. Ultrafiltration (UF) button
27. Treatment history page
28. Status bar
29. Monitor identifier (Nickname)
Note: Treatment overview fields
(11-15) are configurable.
Transmembrane pressure (TMP)
is also available.
1. Venous pressure control
2. Arterial pressure control
3. Machine state indicator
4. Time indicator
5. Blood path
6. Fluid path
7. Blood pressure monitor (BPM) button
8. Blood pressure monitor (BPM)
read out field
9. Diascan read out field
10. Diascan button
11. Blood flow rate
12. Total blood volume processed
13. Total heparin volume infused
14. Total UF volume removed
15. Ultrafiltration rate
16. Alarm tab
1
7
11
16
17
18
20 21 22 23 24
19
3
29
6
9
14 151312
2
10
4
8
5
25 26 27
28
AK 98 CONFIGURATION - SCREEN OVERVIEW
6
