BayTech RPC-2 User Manual

RPC SERIES OWNER’S MANUAL
CABLING
________________________________________________________________________________
18
IMPORTANT
:
Crossed RJ-45 cables are required when modular
connectors are used, as shown in Figures 4 – 6
,
or to interface the
RPC to another BayTech product with modular connectors, such as
the DS-Series data switch.
1
2
3
4
5
6
7
8 8
7
6
5
4
3
2
PIN
RJ-45RJ-45
CONDUCTOR
BLUE
ORANGE
BLACK
RED
GREEN
YELLOW
BROWN
GRAY
PIN
1
GRAY
BROWN
YELLOW
GREEN
RED
BLACK
ORANGE
BLUE
COLOR
COLOR
Figure 7: Crossed 8-pin Modular Cable
BayTech Part No. RJ08X007 (7 feet)
