RPC SERIES OWNER’S MANUAL
DETAILED OPERATION AND CONFIGURATION
________________________________________________________________________________
28
parameters are 9600 bps, 8 data bits, 1 stop
bit, and no parity.
REMOTE ACCESS
USING MODEM
CONNECTIONS
RPC-2 MD01
Using the RJ04X007 (RJ-11) modular cable,
(Internal Modem)
connect either port labeled “LINE” on the
back of the RPC unit to the telco wall jack.
RPC-2 RDR
Plug the modem’s power supply into
(External Modem)
receptacle number six on the RPC. Using the
RJ04X007 (RJ-11) modular cable, connect
either port labeled “LINE” on the back of
the RPC unit to the telco wall jack. Using
another RJ04X007 (RJ-11) modular cable,
connect the remaining port labeled “LINE”
on the back of the RPC unit to the port
labeled “LINE” on the external modem.
(See Figure 1 on page 5.)
Using the 25MRJ45MD-8 adapter and the
RJ08X007 (8-pin crossed) cable, connect the
DB-25 female port of the modem to the RJ-
45 port labeled “EIA-232” on the back of
the RPC unit.
IMPORTANT:
You must customize the external modem’s
configuration to operate properly with the RPC-2 RDR. See
Appendix C (MODEM COMMAND SUMMARY) for information
on customizing external modem configurations.
