RPC SERIES OWNER’S MANUAL
APPENDIX A
________________________________________________________________________________
64
APPENDIX A
SPECIFICATIONS
RPC-
2
RPC-
2A
RPC-2
MDO
1
RPC-2
RDR
RPC-3 RPC-
3A
RPC-5
Power
Receptacle
6 each
115
VAC,
60 Hz,
15 Amp
6 each
230
VAC, 50
Hz,
10 Amp
6 each
115
VAC, 60
Hz,
15 Amp
6 each
115
VAC, 60
Hz,
15 Amp
8 each
115 VAC,
60 Hz,
15 Amp
8 each
230 VAC,
50 Hz,
10 Amp
4 each
115 VAC,
60 Hz,
15 Amp
Circuit
Breaker
125
VAC,
15 Amp
230
VAC, 10
Amp,
Universal
IEC 320
Outlets
125
VAC, 15
Amp
125
VAC, 15
Amp
125 VAC,
15 Amp
230 VAC,
10 Amp,
Universal
IEC 320
Outlets
125 VAC,
15 Amp
4 indiv
breakers
EIA-232
Serial Port
8 pin
modular
connect
or (RJ-
45)
8 pin
modular
connector
(RJ-45)
8 pin
modular
connector
(RJ-45)
8 pin
modular
connector
(RJ-45)
8 pin
modular
connector
(RJ-45)
8 pin
modular
connector
(RJ-45)
8 pin
modular
connector
(RJ-45)
Network
Interface N/A N/A N/A N/A
Ethernet,
IEEE
802.3
compliance
10BASE-T
(twisted
pair RJ-45)
Ethernet,
IEEE
802.3
compliance
10BASE-T
(twisted
pair RJ-45)
Ethernet,
IEEE
802.3
compliance
10BASE-T
(twisted
pair RJ-45)
Protocols N/A N/A N/A N/A
TCP/IP &
Telnet
TCP/IP &
Telnet
TCP/IP &
Telnet
Frame
Types N/A N/A N/A N/A
Ethernet II
and SNAP
Ethernet II
and SNAP
Ethernet II
and SNAP
Modem
Interface N/A N/A 2400 bps N/A N/A N/A N/A
Modem
Connectors N/A N/A
4 pin
modular
RJ-45
4 pin
modular
RJ-45
N/A N/A N/A
Dimensions
16.73”w
x 3.42”d
x 1.72”h
16.73”w
x 4.32”d
x 1.72”h
16.73”w
x 3.42”d
x 1.72”h
16.73”w
x 3.42”d
x 1.72”h
16.73”w x
5.25”d x
1.72”h
16.73”w x
6.17”d x
1.72”h
16.73”w x
6.17”d x
1.72”h
Weight 3 lb, 4
oz
3 lb, 8 oz 3 lb, 4 oz 3 lb, 4 oz 4 lb, 4 oz 4 lb, 8 oz 4 lb, 4 oz
