Becker ACU6100 - Technical Specifications

Becker Avionics
General Description
Technical Data
DV64440.03 Issue 09 November 2019 ACU6100 19
1.8 Technical Data
General Characteristics
ACU6100
Specifications
Supply voltage (Bus) Ⅰ
27.5 VDC nominal
18.0 VDC emergency
Supply voltage (Bus) Ⅱ
27.5 VDC nominal
18.0 VDC emergency
Power consumption
≤ 150 mA inclusive Illumination
Dim control input 1
max. 27.5 VDC (panel illumination)
Dim control input 2
max. 27.5 VDC (LED brightness)
Recommended external fuse protection
2 A T
Control Data Interface ACU-REU
ACU6100
Specifications
Interface
CANbus
Protocol
Becker specific (Becker Bus Protocol proprietary)
Control Inputs (Discrete)
ACU6100
Specifications
PTT
low active ≤ 0.3 V
Hot mike in
low active ≤ 0.3 V
Dimensions & Weight
ACU6100
Specifications
Dimensions HxWxD
75.8 x 145.8 x 91.5 mm
Installation depth
77.5 mm
Weight
≤ 800 g
Standard
ARINC 601, 8 HE
Case material
AlMg
Installation
DZUS fasteners
Device Connectors
ACU6100
Specifications
Device connector
1x 10pol male, bayonet
Control bus connector
1x 19pol male, bayonet
