3.15 Built-In Tests
• The ACU61 device has different built-in tests with optical indication of the test results.
• The tests monitor the system equipment and some internal circuits.
o PBIT: A system self-test starts after power-on.
o CBIT: A background test routine runs continuously during normal operation.
o IBIT: An additional test can be manually started.
Power-on Build-In Test (PBIT)
Power-on Build-In Test (PBIT)
• The ACU6100 powers up with the main system power.
• The test routine will be started (test time ca. 4 s).
o The test status LED (yellow) is on.
• After successful test without failure the test status LED is off.
• If a failure was found the test status LED (yellow) flashes.
There are two procedure to continue, if a failure was found:
• (1) Push at the “TEST” button the failure will be ignored.
o If there is permanent problem inside the system, it will be found by
the continuous self-test routine and indicated again.
• (2) Set the "BACK-UP" switch to slaved or emergency mode (details see
"Emergency Operation" page 60).
Continuous Build-In Test (CBIT)
Continuous Build-In Test (CBIT)
• A background test routine runs continuously during normal operation.
• If a failure was found the test status LED (yellow) flashes.
There are two procedure to continue, if a failure was found:
• (1) Push at the “TEST” button the failure will be ignored.
o If there is permanent problem inside the system, it will be found by
the continuous self-test routine and indicated again.
• (2) Set the "BACK-UP" switch to slaved or emergency mode (details see
"Emergency Operation" page 60).
Initiated Build-In Test (IBIT)
Initiated Build-In Test (IBIT)
• An additional test can be manually started.
• Push the key "TEST" (not during transmission).
• If a failure was found the test status LED (yellow) flashes.
There are two procedure to continue, if a failure was found:
• (1) Push at the “TEST” button the failure will be ignored.
o If there is permanent problem inside the system, it will be found by
the continuous self-test routine and indicated again.
• (2) Set the "BACK-UP" switch to slaved or emergency mode (details see
"Emergency Operation" page 60).
