Connector P2
P2/Pin
Signal name / Function
Remarks
L
Device Address Bit 0
M
Device Address Bit 1
A
Device Address Bit 2
B
Device Address Bit 3
U
Reset out
V
Reset in
N
GND
C
CAN1 in (HI)
D
CAN1 in (LO)
P
CAN1 in (shield)
E
CAN1 out (HI)
F
CAN1 out (LO)
R
CAN1 out (shield)
G
CAN2 in (HI)
H
CAN2 in (LO)
S
CAN2 in (shield)
J
CAN2 out (HI)
K
CAN2 out (LO)
T
CAN2 out (shield
Address Coding
Set the address coding for the control panels (ACU) on the CANbus by pin strapping of
pins L, M, A, B.
For each control panel on the CANbus a unique address is necessary.
