Transceiver Operation
DV64440.03 Issue 09 November 2019 ACU6100 51
3.6 Transceiver Operation
TX-Channel Selection
The channels must be enabled for this function in the configuration.
• Select the channel for transmission with the TX-selector.
o The TX-channel LED is on.
Figure 21: Operation - TX-Channel Selection, TX1
Dual- and Multi Transmission Mode (Simulcast)
Dual- and Multi Transmission Mode (Simulcast)
The channels must be enabled for this function in the configuration.
Used for transmission on more than one channel at the same time.
• Select the mode D (D/S) for transmission with the TX-selector.
o The TX-channel LEDs are on.
NOTICE:
• The selection includes only TX-channels which are configured* to the user
and with enabled rights (TX, Dual, Multi-TX).
*For more information refer to the software manual "CSW6100... "(www.becker-
avionics.com/downloads/ → Intercom).
Relay Mode
The ACU6100 can operate in relay mode alternative to dual TX- and
multi-TX-mode. The channels must be enabled for this function in the
configuration*.
The function is used to:
• Increase the communication range.
• Connect operators of different radio areas/services.
