Volume Adjustment
DV64440.03 Issue 09 November 2019 ACU6100 49
IC Volume Adjustment
• The IC volume is adjustable at any time.
• Turn the inner part of the double rotary knob (IC) to adjust the volume.
Figure 17: Operation - Main Volume
Channel Volume Adjustment
Channel Volume Adjustment
• It is possible to do the volume adjustment for each audio channel.
• Release the related channel (push knobs).
• Turn the knob to adjust the related volume.
Figure 18: Operation - Main Volume
