Chapter 2 General Machine Operation
Typical Wash Structure
Entrance Features
The system is equipped with three Entrance Features that the vehicle receives from the time the Wash Package is
selected until soon after the vehicle arrives at the treadle position. The configuration of these features/functions is very
dynamic. Refer to Chapter 5 Operator Interface/Programming section Setup / Entrance Operation of this manual
to check if these functions are available and can accommodate your special needs. Some examples of the types of
equipment controlled by these features/functions are as follows: CTA, Undercarriage, Soap Arch, Bug Manifold, etc.
Check if equipment to meet your needs is available.
Wash
The wash begins with the Cube® Carriage at the exit of the bay when the vehicle pulls onto the treadle position. The
Carriage will traverse on the frame rails, each motion of the Carriage from (front to back) or (back to front) is considered
one pass. The machine moves back and forth over the full length of the vehicle in pass order determined by the
Package. The pass order of each Package may be changed. When all the passes are complete, the machine will
instruct the driver to pull forward. If the machine is not at the exit when the wash is finished it will move rapidly to the
exit position.
Exit Features
The system is equipped with three Exit Features. These are features/functions that the vehicle receives as it is pulling
out of the bay after wash is complete. The configuration of these functions is very dynamic. Refer to Chapter 5
Operator Interface/Programming section Setup / Exit Operation of this manual to check if these functions are
available and can accommodate your special needs. Some examples of the types of equipment controlled by these
features/functions are as follows: Dryer, Wax Arch, Spot Free Arch, etc. Check if equipment to meet your needs is
available.
Receive none or up
to 3 Entrance
Features
Wash package
selected
Get to
treadle
Position
Receive wash
Receive none or up
to 3 Exit Features
Wash package selected may
be performed in many ways.
Some typical methods are as
follows:
• POS (Point of Sales)
• Push Buttons
• Fleet Loader Photo-Eye
The three entrance features can
be turned on or off with many
combinations of the following:
• Wash Package Selected
• Make or break beam of up to
3 Photo-Eyes
• Max Time
• Treadle Position
The three exit features can
be turned on or off with
many combinations of the
following:
• Wash End
• Make or break beam
of up to 2 Photo-Eyes
• Any point in wash
• Max Time
• Treadle
Wash can be configured by
selecting pass order of pre-
defined applications such as:
Soap, Rinse, Drying Agent,
Sealer Wax, etc.
The system has 12 different
user-defined applications.
