CUBE® CONTROLLER
1MANUL964 Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 4-1
Chapter 4 Operator Interface / Standard User Screens
Queue
• The row of boxes displays the ten
packages in QUEUE, 0 if not
present
• The field to the right of the arrow is
where you will enter the next
available Package
• LOADER shows the wash that is
being evaluated to load
• WASH shows the vehicle that has
been pulled from loader typically
occurs when the vehicle has
entered the Photo-Eye beam
The QUEUE keeps track of the packages that vehicles will receive. It can keep track of up to 10 vehicles at a time.
Package selections can be entered into the QUEUE from the screen ONLY. The POS and Fleet Mode will enter
selections directly into the Loader.
Values entered in the QUEUE will be inserted to the left of the last position entered. If package is the first entered into
QUEUE, it will be inserted into the right most position. As washes are used, the QUEUE will shift all packages to the right
one place until all washes are shifted into the Loader.
Note: POS and Fleet mode will NOT use QUEUE; it will insert selections directly into the Loader.
When the system is ready to accept another vehicle into the wash, the Loader will be shifted into wash if Entrance
Operation 1 “On Condition” is met.
Entrance Operation 1 will need to be configured even if not used in packages.
Note: See Entrance Operation 1 for conditions to move package from Loader to wash.
