Belanger Full Side Washer - Head Assembly (Electric)

FULL SIDE WASHER
1MANUL854 Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 41
Maintenance
Exploded Parts View
Head Assembly (Electric)
1FSTNR-PH040 (2)
1COLLR333
1ELECT-FS855 (4)
Black: PLSTC-CV080
Blue: PLSTC-CV082
Green: PLSTC-CV088
Gray: PLSTC-CV092
Orange: PLSTC-CV086
Red: PLSTC-CV084
Yellow: PLSTC-CV090
1PLSTC-CV075
1FSTNR-HH045 (3)
See Chart
See Chart
112286: Std. Voltage
112297: 380/400-415 Volts
112288: 575 Volts
7918
1WASHR-LC125 (3)
1FSTNR-PH040 (2)
1ELECT-FS855 (4)
7912
1GEABX-KT250
Torque Plate: 108661
See Exploded View Below
1FSTNR-FH075 (8)
108661: Torque Plate with
Grommets
1GRMIT222 (2)
108634
