FULL SIDE WASHER
1MANUL854 Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 21
Installation
Waves and Fins Cleaning Material
Shaft Brackets
1) Locate the Side Wheel Wave boxes and open them upside down to expose the drive plate
assemblies.
2) Remove the drive plates and secure them to the wheel shafts at 10-1/2” above the floor by
tightening the shaft brackets into place.
