FULL SIDE WASHER
1MANUL854 Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 55
Maintenance
Exploded Parts View
Neo-Tex™ Wash Clips
1PLSTC-CL025 (8” Wash Clip)
1PLSTC-CL050 (10” Wash Clip)
Neo-Tex
™
Fill Pattern
Overhead View of
Upper Hub Fill
Pattern
(6” diameter hub)
Fill Slots As Shown
Overhead View of Lower
Hub Fill Pattern
(12” diameter hub)
Fill every other slot
as shown
