[E62] – [E63]
INFO [E62] Various Information.
• Voltage Shows low voltage measured inside the machine on the main board. If this falls under 10,0V
you will get an error message (”LOW BATTERY!”) accompanied by a constant beep. The sound
disappears when the voltage rises over 10,0V. Press any button to stop the sound.
• Boost volt Internal battery voltage. Normal voltage is between 33-40V.
• Temperature Temperature measured inside the machine in (C°).
• Motor current Motors current use measured in Amps.
• Damp value upper sensor Damp inside of the machine measured from the upper edge.
• Damp value lower sensor Damp inside of the machine measured from the lower edge.
• Wheel speed. Shows the speed of the Wheel in Rpm.
• Motor speed Shows the speed of the Motor in Rpm.
• Serial number. This screen shows information that shall be sent in any support case, for best service
support. Serial number of both electronic cards KEX (Keyboard) and MEX (Mainboard) shows
toghether with program firmware and cpu device used in the machine.
BEEP AT – Pressing button [E63] Decided if the sounder shall sound when pushing buttons.
Four settings are availiable.
• ”Local and extern” Sounds both when pushing local buttons, and when beeing remote controlled.
• ”External only” No sound for pressing local buttons, but it sounds when beeing remote controlled.
• ”Local only” Sounds only when pressing local buttons. No sound when beeing remote controlled.
• ”Never” No sound at all when buttons are pushed.
BEEP – Number at catch [E63 P] How many times the machine will beep when catch is registered. It
can either be turned off by choosing ”OFF”, or can be set from 1 to 99 beeps.
BEEP – Pause at catch at Zeropoint [E63 PP] When the machine has hauled up the catch you get a
longer beep and a longer pause, up to 60 seconds pause. You can turn this off by choosing ”OFF”.
INFO[E62] - PIP[E63]
Screens Min Max Factory Step Unit Navigation
MORE - INFO [E62]
