Bender CC612 User Manual

FunctionFunction
CC612(4G)_D00325_04_M_XXEN/03.2019
11
3.3.2 Way of connecting with Type 2 socket
–
+
IN
M
–
+
A
CP
PP
PE
N L1
L2
L3
e
L1
L2
L3
N
PE
PP CP
PE
L1 N
L3
L2
f
12V 0V 11 14
B
1
2
3
4
5
6
D
C
– OUT + IN
A
RJ10
F
RJ45
E
CC612
ALARM
READY
PLC
USB 1
SIM
CONFIG
B
A
PP
IN1–
IN2–
21
IN1+
IN2+
CP
24
C
IN2–
IN2+
n
IN1–
IN1+
m
21
24
j
PP
CP
g
h
14
11
0V
12V
i
AC
DC
0 V
12 V
b
d
H
V
a
c
CC612 Charge Controller
Bottom view
Frontal view
Top view
Mennekes
Type 2 socket *
Legend
Assignment of the terminals
Charge Controller CC612
The SIM card slot and antenna socket are available on Master variants
only. Master variants are:
CC612-1M4PR
CC612-2M4PR
CC612-2M4R
PLC is optional.
Relay
The relay used to control the contactor is rated for 30 V/1 A. An interme-
diate relay may be required if this rating is inadequate.
Contactor
The relay contactor can also be connected to a cable with a type 1 or
type 2 plug.
A Connection locking engine d Contactor
B Connection socket User Interface
e Type 2 socket*
C Connection socket
f Type 2 plug*
D Connection Current Transformer (CT)
g Connection Proximity Pilot
E Connection User Interface (RJ45)
h Connection Control Pilot
F Connection Modbus/eHZ meter (RJ10)
i Relay 1: Control pin contactor
a RCD Type A j Output relay 2
b Voltage supply DC 12V m Optocoupler input 1
c Current Transformer (CT) with plug n Optocoupler input 2
A1 IN C1 PP
A2 + C2 CP
A3 OUT C3 21
A4 - C4 24
B1 12V
C5 IN1-
B2 0V
C6 IN1+
B3 11
C7 IN2-
B4 14
C8 IN2+
