ConnectionConnection
CC612(4G)_D00325_04_M_XXEN/03.2019
25
• Display module DPM2x16FP - The display module is also a separate PCB that is
used to indicate the charge controller status information as well as the charging sta-
tus. It features two RJ45 cable sockets, one which connects to the charge controller
and the other which can connect to the RFID module.
•
5.2.2 Master device features
Only datagateways with 4G modem feature a SIM card/SIM card slot and an antenna
socket.
5.2.2.1 SIM card and SIM card slot
• The charge controller supports 4G mobile networks and an integrated modem is
included. It uses a wireless module, which supports the following European fre-
quency bands:
• LTE FDD: 800 MHz band 20, 900 MHz band 8, 1,800 MHz band 3,
2,100 MHz band 1 and 2,600 MHz band 7
• GSM: 900 MHz band 8 and 1,800 MHz band 3
• WCDMA: 850 MHz band 5, 900 MHz band 8, and 2,100 MHz band 1
• The charge controller can be operated as an "always-on" system when connected to
a mobile phone data network,
• Connection is only possible when a SIM card is inserted into the SIM card slot loca-
ted on the charge controller front panel. SIM must be provided in micro SIM format.
• The SIM card can have a PIN number which can be configured via the Operator con-
figuration web interface (http://192.168.123.123/operator).
• The APN settings for the card can also be configured via the Settings configuration
web interface.
Connection to the mobile network (and subsequently the backend system) usually lasts
between 6 to 48 hours after which the connection may be terminated by the mobile net-
The display module is described in a separate operating manual (docu-
ment number D00296), which can be downloaded from
www.bender.de/en/service-support/downloads.
work. The charging system detects this disconnection and automatically reconnects.
Geographical application
An integrated 4G modem may be operated in the following countries only. If 4G mobile
networks are not supported, GSM mobile networks may also be used.
5.2.2.2 Antenna socket
An antenna socket connects to a 4G antenna.
The SIM card is not included within the scope of delivery.
The use of Nano SIM cards with a corresponding SIM card adapter may
damage the SIM card slot.
Therefore, it is recommended to use only Micro SIM cards.
Austria Latvia, Lithuania, Luxembourg
Belgium, Bulgaria Malta, Madeira
Croatia, Cyprus, Czech Republic,
Canary Islands
Poland, Portugal
Denmark Romania
Estonia Slovakia, Slovenia, Spain, Sweden
Germany, Great Britain, Greece The Azores
Finland, France
Netherlands, Hungary
Ireland, Italy
The following approved antenna must be used:
Panorama Antennas B4BE-7-27-05SP
The antenna is not included within the scope of delivery.
