Bender CC612 User Manual

Configuration and testingConfiguration and testing
CC612(4G)_D00325_04_M_XXEN/03.2019
30
6.3 Settings tab
Parameter Description
ChargePoint ID (OCPP)
OCCP Charge Point ID which is used to identify
itself towards the backend system. If two or
more Slave devices are connected, each Slave
must identify itself to the Master with its respec-
tive connector ID added as a suffix. E.g. #2 or
#005 should be appended to the Charge Point
ID. Please note that suffixes #, #0 or #1 are reser-
ved and cannot be used.
Connection Type
The type of data connection to be used to
connect to the backend system, if any. Use this
option to disable backend communication
completely.
Access Point Name (APN)
Access Point Name of the mobile network to be
used when establishing connections to the
backend system via the built-in 4G modem.
APN Username
Username to be used for authenticating with the
Access Point of the 4G network for connecting
with the backend system.
APN Password
Password to be used for authenticating with the
Access Point of the 4G network for connecting
with the backend system.
OCPP Mode
This parameter determines whether backend
communication is done using the standard OCPP
SOAP/JSON variant or the proprietary Binary
OCPP variant of Ebee Smart Technologies. The
Binary OCPP variant is working across NAT
networks and therefore does not require a
private APN for remote messages to arrive at the
charge point. Also Binary OCPP uses much less
data (factor 20 to 50) than standard OCPP. Binary
OCPP however requires a Binary OCPP proxy on
the backend side.
SOAP OCPP URL of Backend
(Standard OCPP)
The HTTP URL of the OCPP backend system. This
URL must be the SOAP end point. This parameter
is only used if OCPP-S 1.5 or 1.6, the standard
OCPP mode is used. If this mode is used, a SIM
card with a private APN must be used if the
charge point should receive remote commands
from the backend system as most 4G networks
use NAT for normal SIM cards which prevents
connections from the backend to the charge
point.
Hostname (Binary OCPP)
The DNS hostname or IP address of the binary
OCPP proxy server for the backend system. This
parameter is only used if Binary OCPP is selected
for the TCP/IP mode.
Portnumber (Binary OCPP)
The TCP port of the proxy server for Binary OCPP
communication with the backend system
WebSockets JSON OCPP URL of the
Backend
The WS/WSS URL of the OCPP backend system.
This URL must be the WS/JSON end point. This
parameter is only used if OCPP-J 1.6 mode is
used. The charge point ID gets automatically
appended when connecting to the backend.
Free charging
This mode allows charging without authorization
via RFID or the backend. Charging is started
immediately after a vehicle is connected.
Operator Current Limit (A)
The current in Ampere that is signaled to the
vehicle for charging. This value must be below
the maximum current (see state view) of the
charger, but can be freely configured, even while
charging. NOTE: Value is overwritten when peer
group configured.
Parameter Description
