CC612(4G)_D00325_04_M_XXEN/03.2019
15
Connection
5. Connection
5.1 Connection conditions
Connect PE to "0V"; reference level for Control Pilot (CP communication) must be at
same level as the power supply (IEC 61851 standard).
Cable lengths (except Modbus, Power IN and charging cable) < 3 m; cables must be
positioned inside the wallbox/charging station and should not be laid parallel to
power cables.
Modbus (A, B) must be connected using a shielded cable; connect shield to PE.
DANGER
Risk of electric shock!
Parts of the system can be energised (he charge controller terminals up to
12 V, the charging system voltage is 230 V). Before touching live parts of
the system, ensure that the installation has been de-energised.
CAUTION
Risk of injury from sharp-edged terminals. Handle housing and terminals
with care.
