Modbus register assignment of the ISOMETER®
50
isoRW425_D00052_03_M_XXEN / 02.2017
( ) = Channel description code (refer to Chapter 8.2 )
[ ] = Alarm type (refer to Chapter 8.1.2.2 )
1032
to
1035
Actual meas-
urement ---
(1022) [no
alarm]
--- ---
---
Device
fault (115)
[device
fault
Register
Permissi
ons
Description Format Unit Value range
3000 RW Reserved --- --- ---
3001 RW
Pre-alarm value
impedance
measurement
"Z1"
UINT 16 k Z2 … 500
3002 RW Reserved --- --- ---
3003 RW
Alarm value
impedance
measurement
"Z2"
UINT 16 k 10 … Z1
Register
Measuring value
Device
fault
Without
alarm
Alarm 1 Alarm 2
