4.5 Display contrast adjustments

When low-level backlight is activated press and hold BACKLIGHT key until the Display contrast

adjustment menu is displayed.

Fig. 4.9: Contrast adjustment menu

Use the and keys to adjust the contrast level. Press the TEST key to accept the new setting.
