Benning IT 110 - Fuse Base Tables

65
Fuse,
utilisation
class / type
Fuse, total
clearing
time
Fuse,
rated
current
Pros pec-
tive short-
circuit
current
(A), low
value
Fuse,
utilisation
class / type
Fuse, total
clearing
time
Fuse,
rated
current
Pros pec-
tive short-
circuit
current
(A), low
value
gL-gG (NV, gG) 35 ms 2 A 32.5
gL-gG (NV, gG) 35 ms 4 A 65.6
gL-gG (NV, gG) 35 ms 6 A 102.8
gL-gG (NV, gG) 35 ms 10 A 165.8
gL-gG (NV, gG) 35 ms 13 A 193.1
gL-gG (NV, gG) 35 ms 16 A 206.9
gL-gG (NV, gG) 35 ms 20 A 276.8
gL-gG (NV, gG) 35 ms 25 A 361.3
gL-gG (NV, gG) 35 ms 32 A 539.1
gL-gG (NV, gG) 35 ms 35 A 618.1
gL-gG (NV, gG) 35 ms 40 A 694.2
gL-gG (NV, gG) 35 ms 50 A 919.2
gL-gG (NV, gG) 35 ms 63 A 1217.2
gL-gG (NV, gG) 35 ms 80 A 1567.2
gL-gG (NV, gG) 35 ms 100 A 2075.3
gL-gG (NV, gG) 35 ms 125 A 2826.3
gL-gG (NV, gG) 35 ms 160 A 3538.2
gL-gG (NV, gG) 35 ms 200 A 4555.5
gL-gG (NV, gG) 35 ms 250 A 6032.4
gL-gG (NV, gG) 35 ms 315 A 7766.8
gL-gG (NV, gG) 35 ms 400 A 10577.7
gL-gG (NV, gG) 35 ms 500 A 13619
gL-gG (NV, gG) 35 ms 630 A 19619.3
gL-gG (NV, gG) 35 ms 710 A 19712.3
gL-gG (NV, gG) 35 ms 800 A 25260.3
gL-gG (NV, gG) 35 ms 1000 A 34402.1
gL-gG (NV, gG) 35 ms 1250 A 45555.1
gL-gG (NV, gG) 0.1 s 2 A 22.3
gL-gG (NV, gG) 0.1 s 4 A 46.4
gL-gG (NV, gG) 0.1 s 6 A 70
gL-gG (NV, gG) 0.1 s 10 A 115.3
gL-gG (NV, gG) 0.1 s 13 A 144.8
gL-gG (NV, gG) 0.1 s 16 A 150.8
gL-gG (NV, gG) 0.1 s 20 A 204.2
gL-gG (NV, gG) 0.1 s 25 A 257.5
gL-gG (NV, gG) 0.1 s 32 A 361.5
gL-gG (NV, gG) 0.1 s 35 A 453.2
gL-gG (NV, gG) 0.1 s 40 A 464.2
gL-gG (NV, gG) 0.1 s 50 A 640
gL-gG (NV, gG) 0.1 s 63 A 821.7
gL-gG (NV, gG) 0.1 s 80 A 1133.1
gL-gG (NV, gG) 0.1 s 100 A 1429
gL-gG (NV, gG) 0.1 s 125 A 2006
gL-gG (NV, gG) 0.1 s 160 A 2485.1
gL-gG (NV, gG) 0.1 s 200 A 3488.5
gL-gG (NV, gG) 0.1 s 250 A 4399.6
gL-gG (NV, gG) 0.1 s 315 A 6066.6
gL-gG (NV, gG) 0.1 s 400 A 7929.1
gL-gG (NV, gG) 0.1 s 500 A 10933.5
gL-gG (NV, gG) 0.1 s 630 A 14037.4
gL-gG (NV, gG) 0.1 s 710 A 17766.9
gL-gG (NV, gG) 0.1 s 800 A 20059.8
gL-gG (NV, gG) 0.1 s 1000 A 23555.5
gL-gG (NV, gG) 0.1 s 1250 A 36152.6
gL-gG (NV, gG) 0.2 s 2 A 18.7
gL-gG (NV, gG) 0.2 s 4 A 38.8
gL-gG (NV, gG) 0.2 s 6 A 56.5
gL-gG (NV, gG) 0.2 s 10 A 96.5
gL-gG (NV, gG) 0.2 s 13 A 117.9
gL-gG (NV, gG) 0.2 s 16 A 126.1
gL-gG (NV, gG) 0.2 s 20 A 170.8
gL-gG (NV, gG) 0.2 s 25 A 215.4
gL-gG (NV, gG) 0.2 s 32 A 307.9
gL-gG (NV, gG) 0.2 s 35 A 374
gL-gG (NV, gG) 0.2 s 40 A 381.4
gL-gG (NV, gG) 0.2 s 50 A 545
gL-gG (NV, gG) 0.2 s 63 A 663.3
gL-gG (NV, gG) 0.2 s 80 A 964.9
gL-gG (NV, gG) 0.2 s 100 A 1195.4
gL-gG (NV, gG) 0.2 s 125 A 1708.3
gL-gG (NV, gG) 0.2 s 160 A 2042.1
gL-gG (NV, gG) 0.2 s 200 A 2970.8
gL-gG (NV, gG) 0.2 s 250 A 3615.3
gL-gG (NV, gG) 0.2 s 315 A 4985.1
gL-gG (NV, gG) 0.2 s 400 A 6632.9
gL-gG (NV, gG) 0.2 s 500 A 8825.4
gL-gG (NV, gG) 0.2 s 630 A 11534.9
gL-gG (NV, gG) 0.2 s 710 A 14341.3
gL-gG (NV, gG) 0.2 s 800 A 16192.1
gL-gG (NV, gG) 0.2 s 1000 A 19356.3
gL-gG (NV, gG) 0.2 s 1250 A 29182.1
gL-gG (NV, gG) 0.4 s 2 A 15.9
gL-gG (NV, gG) 0.4 s 4 A 31.9
gL-gG (NV, gG) 0.4 s 6 A 46.4
gL-gG (NV, gG) 0.4 s 10 A 80.7
gL-gG (NV, gG) 0.4 s 13 A 100
gL-gG (NV, gG) 0.4 s 16 A 107.4
gL-gG (NV, gG) 0.4 s 20 A 145.5
gL-gG (NV, gG) 0.4 s 25 A 180.2
gL-gG (NV, gG) 0.4 s 32 A 271.7
gL-gG (NV, gG) 0.4 s 35 A 308.7
gL-gG (NV, gG) 0.4 s 40 A 319.1
gL-gG (NV, gG) 0.4 s 50 A 464.2
gL-gG (NV, gG) 0.4 s 63 A 545
10.1 Fuse base tables
