BenQ LU9715 - Specifications; Technical Specifications Overview

English
60
Specications
Model LU9715
Display Device Single Chip 0.67” DLP Technology
Resolution WUXGA
Input
Terminals
HDMI
(Compatible with HDCP)
1
DVI-D
(Compatible with HDCP)
1
Display Port
(Compatible with HDCP)
1
3G-SDI In
(Compatible with HDCP)
1
Computer-1
(D-sub 15p)
1
Computer-2
(5BNC)
1
HDBaseT
(Shared with RJ-45)
1
Output
Terminals
Monitor Out
(D-sub 15 p)
1
Trigger
(
φ
3.5mm stereo min jack)
X1(DC 12V Output)
3D IR Sync
(VESA mini din)
1
3G-SDI Out 1
Control and
Service
Lan (RJ-45) 1
Wired Remote
(
φ
3.5mm stereo min jack)
1
RS-232 1
Power Requirement AC 100-130V AC 200-240V
Input Current 9.50A 4.50A
Power Consumption
(Normal Mode)
885W@110 V (max), 845W@220V (max)
Operation Temperature 32ºF to 104ºF (0ºC to 40ºC )
Storage Temperature
14ºF to 140ºF (-10ºC to 60ºC), 5% to 95%
Humidity (non-condensing)
Dimensions
22.95˝ x 19.6˝ x 8.31˝
583mm(L) x 500mm(W) x 211mm(H)
(not including protrusions or feet)
Net Weight (Projector Only) 28kg
