the top cover is removed.
SWITCH B(x2):Will be activated when the
projection lens is removed.
Laser parameters
Blue Laser Diode Wavelength: 450nm - 460nm
Mode of Operation: Pulsed, due to frame rate
Pulse width: 0.74ms
Pulse repetition rate: 240Hz
Maximum laser energy: 0.376mJ
Total internal power: >100W
Apparent source size: >10mm, at lens stop
Divergence: >100 mili Radian
