Timing chart
The following table shows compatible signal types, their resolution and frequency refresh rates.
Horizontal: 15kHz, 31kHz to 90 kHz, Vertical: 50 Hz to 85 Hz.
Signal
Format
Resolution Frame
Rate
(Hz)
Computer
1,2 -SOG
Computer 1,2 -
RGBHV
DisplayPort
/ DVI-D
HDMI /
HD-BaseT
HD/
SDI
RGB YUV 3G
8-bit 10-bit 12-bit
PC
640x480 59.94 X X X X
640x480 74.99 X X X X
640x480 85 X X X X
800x600 60.32 X X X X
800x600 75 X X X X
800x600 85.06 X X X X
848x480 47.95 X X X X
848x480 59.94 X X X X
1024x768 60 X X X X
1024x768 75 X X X X
1024x768 85 X X X X
1152x864 75 X X X X
1280x720 47.95 X X X X
1280x800 75 X X X X
1280x1024 60.02 X X X X
1280x1024 75.02 X X X X
1280x1024 85.02 X X X X
1366x768 60 X X X X
1600x1200 60 X X X X
1920x1080 47.95 X X X X
1680x1050 59.94 X X X X
1920x1200 RB 50 X X X X
1920x1200 RB 60 X X X X
1400X1050 60 X X X X
1366 x 768 60 X X X X
1440 x 900 60 X X X X
1280 x 768 60 X X X X
1280 x 800 60 X X X X
1280 x 960 60 X X X X
Apple Mac
640x480 66.59 X X X X
832x624 74.54 X X X X
1024x768 75 X X X X
1152x870 75 X X X X
SDTV
480i 59.94 X X
1440x480i 60 X X X X
1440x576i 50 X X X X
576i 50 X X
EDTV
480p 59.94 X X X X X X X X
576p 50 X X X X X X X X
