APPENDIX C - SPARE PARTS
Description Part Number Size
1) LCD Display (small) KPMX3SLCD H=63mm (2.48"), W=101mm (4")
2) LCD Display (large) KPMX3LLCD H=77mm (3.03"), W=127mm (5")
3) LCD display cable
RI-100008-00
RI-100009-00
3' or 1 meter
6' or 2 meter
4) Communication Modules -consult factory
Description Part Number Size Quantity
1) LCD Display
small = KPMX3SLCD H=63mm (2.48"), W=101mm (4")
large = KPMX3LLCD H=77mm (3.03"), W=127mm (5")
2) LCD Display Cable
short = RI-100008-00
long = RI-100009-00
3' or 1m
6' or 2m
3) Cooling Fans 4" – 6"
4) Stack O/T Switch 3
5) Current Transformer (CTs)
CT288:1
CT864:1
CT2640:1
CT5760:1
288:1
864:1
2640:1
5760:1
6) MX
2
card PC-300055-01-05
7) DV/DT Board PC-300048-01-02 3
8) Control Power Transformers VA & Voltage specific
9) SCRs
BISCR5016x
BISCR10016x
BISCR13216x
BISCR16116x
BISCR25016x
3 / Starter
BISCR66018x
BISCR88018x
BISCR150018x
6 / Starter
10) Contactors
RSC-9-6AC120 RSC-100-4120
RSC-12-6AC120 RSC-125-4120
RSC-18-6AC120 RSC-150-4120
RSC-22-6AC120 RSC-180-4120
RSC-32-6AC120 RSC-220-4120
RSC-40-6AC120 RSC-300-4120
RSC-50-6AC120 RSC-400-4120
RSC-75-6AC120 RSC-600-4120
RSC-85-6AC120 RSC-800-4120
RSC-85/4-6AC-120
