BENSHAW RediStart RB2 User Manual

200
APPENDIX E - MODBUS REGISTER MAP
Absolute Register Address Description Range Units
30026/40026 Lockout Status
Bit 0: “L OL” – Motor overload
Bit 1: – Reserved - (Motor PTC)
Bit 2: – Reserved - (RTD Stator)
Bit 3: – Reserved - (RTD Bearing)
Bit 4: – Reserved - (RTD Other)
Bit 5: "L rI" – Run Interlock
Bit 6: "L dS" – Disconnect open
Bit 7: "L Ot" – Stack overtemperature
Bit 8: "L CP" – Control Power
Bit 9: Reserved – (RTD Open/Short)
Bit 10: Reserved – (Time between starts)
Bit 11: Reserved – (Backspin)
Bit 12: Reserved – (Starts per hour)
Bit 13 Reserved – (RTD Comm Loss)
-
30027/40027 Present Fault Code
30028/40028 Average Current A
rms
30029/40029 L1 Current A
rms
30030/40030
L2 Current
A
rms
30031/40031 L3 Current A
rms
30032/40032 Current Imbalance 0.1 %
30033/40033 Residual Ground Fault Current % FLA
30034/40034 Reserved -
30035/40035 Average Voltage V
rms
30036/40036 L1-L2 Voltage V
rms
30037/40037 L2-L3 Voltage V
rms
30038/40038 L3-L1 Voltage V
rms
30039/40039 Motor Overload %
30040/40040 Power Factor
-99 to +100
(in 16-bit two’s compliment signed format)
0.01
30041/40041 Watts (lower 16 bits)
(in 32-bit unsigned integer format) W
30042/40042 Watts (upper 16 bits)
30043/40043 VA (lower 16 bits)
(in 32-bit unsigned integer format) VA
30044/40044 VA (upper 16 bits)
30045/40045 vars (lower 16 bits)
(in 32-bit two’s compliment signed integer
format)
var
30046/40046 vars (upper 16 bits)
30047/40047 kW hours (lower 16 bits)
(in 32-bit unsigned integer format)
kWh
30048/40048 kW hours (upper16 bits)
30049/40049 Phase Order
0: no line
1: ABC
2: CBA
3: SPH
-
30050/40050 Line Frequency
230 – 720, or 0 if no line
0.1 Hz
30051/40051 Analog Input %
-1000 to +1000
(in 16-bit two’s compliment signed format)
0.1 %
30052/40052
Analog Output %
0 – 1000
0.1 %
30053/40053 Running Time
0 – 65535
hours
30054/40054 Running Time
0 – 59
minutes
30055/40055 Starts -
30056/40056 TruTorque % %
30057/40057 Power % %
30058/40058 Peak Starting Current A
rms
30059/40059 Last Starting Duration 0.1 Sec
30101/40101 Motor FLA 1 – 6400 A
rms
30102/40102 Motor Service Factor 100 – 199 0.01
30103/40103 Independent Start/Run Motor Overloads
0: Disabled
1: Enabled
-
