APPENDIX E - MODBUS REGISTER MAP
Absolute Register Address Description Range Units
30104/40104 Motor Overload Running Enable
0: Disabled
1: Enabled
-
30105/40105 Motor Overload Running Class 1 – 40 -
30106/40106 Motor Overload Starting Enable
0: Disabled
1: Enabled
-
30107/40107 Motor Overload Starting Class 1 – 40
30108/40108 Motor Overload Hot/Cold Ratio 0 – 99 %
30109/40109 Motor Overload Cooling Time 10 – 9999 0.1 Min
30110/40110 Local Source 0: Keypad
1: Terminal
2: Serial
-
30111/40111 Remote Source
30112/40112 Start Mode
0: Open Loop Voltage Ramp
1: Closed Loop Current Ramp
2: TruTorque Ramp
3: Power Ramp
-
30113/40113 Initial Motor Current 1 50 – 600 % FLA
30114/40114 Maximum Motor Current 1 100 – 800 % FLA
30115/40115 Ramp Time 1 0 – 300 Sec
30116/40116 Initial Motor Current 2 50 – 600 % FLA
30117/40117 Maximum Motor Current 2 100 – 800 % FLA
30118/40118 Ramp Time 2 0 – 300 Sec
30119/40119 UTS Time 1 – 900 Sec
30120/40120 Initial V/T/P 1 – 100 %
30121/40121 Max T/P 10 – 325 %
30122/40122 Stop Mode
0: Coast
1: Voltage Decel
2: TruTorqu Decel
3: DC Brake
-
30123/40123 Decel Begin Level 100 – 1 %
30124/40124 Decel End Level 99 – 1 %
30125/40125 Decel Time 1 – 180 Sec
30126/40126 DC Brake Level 10 – 100 %
30127/40127 DC Brake Time 1 – 180 Sec
30128/40128 DC Brake Delay 1 – 30 100 mSec
30129/40129 Kick Enable 1
0: Disabled
1: Enabled
-
30130/40130 Kick Current Level 1 100 – 800 % FLA
30131/40131 Kick Time 1 1 – 100 100 mSec
30132/40132 Kick Enable 2
0: Disabled
1: Enabled
-
30133/40133 Kick Current Level 2 100 – 800 % FLA
30134/40134 Kick Time 2 1 – 100 100 mSec
30135/40135 Slow Speed Enable
0: Disabled
1: Enabled
-
30136/40136 Slow Speed
0: 7.1
1: 14.3
%
30137/40137 Slow Speed Current Level 10 – 400 % FLA
30138/40138 Slow Speed Time Limit Enable
0: Disabled
1: Enabled
-
30139/40139 Slow Speed Time Limit 1 – 900 Sec
30140/40140 Slow Speed Kick Enable
0: Disabled
1: Enabled
-
30141/40141 Slow Speed Kick Level 100 – 800 % FLA
30142/40142 Slow Speed Kick Time 1 – 100 100 mSec
